High Torque Single Phase Motors
Motovario Motors
Motovario's HSE series high starting torque single-phase motors are engineered to deliver reliable performance in applications where robust start-up is critical. Compliant with IEC standards, these motors are available in frame sizes 63 to 100 and power outputs ranging from 0.12 kW to 2.2 kW. Their design ensures compatibility with various mounting options, including B3 (foot), B5, and B14 (flange) configurations, making them versatile for integration into diverse machinery setups.
Features
The Motovario HSE series single-phase motors are built to deliver exceptional performance in applications requiring high starting torque. Each motor features a robust aluminium or die-cast aluminium alloy cage rotor combined with external surface ventilation to ensure efficient thermal management during demanding operations. These motors conform to IEC 34 and IEC 72-1 standards and are protected to IP55, offering strong resistance against dust and water ingress. With insulation class F or H, they are well-suited for harsh working environments, supporting ambient temperatures up to +40°C and installation at altitudes up to 1,000 meters above sea level. Their flexible mounting options available in foot (B3), flange (B5), and face (B14) configurations, make them adaptable for a variety of equipment setups.
Technical Specifications
- Power Range: 0.12 kW to 2.2 kW
- Frame Sizes: IEC 63 to 100
- Polarity: 4-pole
- Mounting Options: B3, B5, B14
- Protection Class: IP55
- Insulation Class: F or H
- Ambient Temperature: Up to +40°C
- Available Certifications: EAC, CE, UKCA
Applications
- Compressors
- Pumps
- Conveyors
- Fans and Blowers
