TEC Three Phase Electric Motor, 0.75KW, (1HP), Foot Mounted(B3), 3000rpm(2 pole), IE3 efficiency, 80M Frame, Aluminium Body

OUTPUT POWER (KW)

0.75

Mounting

Foot B3

Construction

Aluminium

Phase

Three Phase

Efficiency

IE3

Output Speed

3000

£ 72.46(ex VAT)

Add to basket
  • Product Description
  • Product Specifications
  • Technical Specification
  • Downloads

This highly AC efficienct electric motor has a power rating of 0.75kW, manufactured by TEC Electric Motors and has an output speed of 3000rpm. Note: 3000rpm is the standard speed of the motor. The output speed is dictated by the Hz frequency and therefore this motor will also be appropriate to use if your output speed is 2800rpm, 2850rpm, 2900rpm or 2750rpm etc. This unit can be described as a 0.75kW, (1HP,) 3000rpm, Three Phase,IE3, Foot mounted (B3), 80M Frame in a Aluminium Body. This unit has a net weight of 8.9Kg. The alternative reference is 0.7523TECAB3 – IE3. If you require additional information please contact Sales on 01952 676925.

KW 0.75
HP 1
Frame 80M
Mount Foot B3
Material Aluminium
Input Three Phase
Output Speed 3000
Shaft Diameter φ19
Shaft Length 40
Part Number ZD1200929
Manufacturer 0.7523TECAB3-IE3
Product Group Electric Motors
